Standard Design Manufactured by WHA
G-14
Low-Velocity Cargo Parachute
A 34-foot low-velocity cargo parachute for light aerial delivery applications.
View systemWHA Military / Cargo
Cargo Parachute Systems
Light, medium and heavy cargo parachutes for aerial resupply and equipment delivery.
Size progression
Light → Medium → Heavy
Nominal canopy diameter is shown at a common visual scale. Capacity values are published single-parachute figures, not cluster-load claims.
Available systems
Cargo Parachutes
Light, medium and heavy aerial delivery systems
Standard Design Manufactured by WHA
G-12
Cargo Parachute
A 64-foot medium-capacity cargo parachute with G-12D and G-12E maintained as separate procurement variants.
View system
Standard Design Manufactured by WHA
G-11
Cargo Parachute
A 100-foot heavy cargo parachute with B, C and D models retained as separate variants pending controlled reference mapping.
View system
WHA Manufactured
Specialized Systems
Mission-Specific Aerial Delivery Parachutes
Specialized parachute solutions configured for extraction, deceleration, stabilization, illumination and mission-specific aerial delivery requirements.
View systemCargo comparison
Single-parachute reference
Cluster configurations are identified and evaluated separately.
| Product | Class | Nominal diameter | Published single-parachute capacity |
|---|---|---|---|
| G-14 | Light | 34 ft / 10.4 m | up to 500 lb / 227 kg |
| G-12 | Medium | 64 ft / 19.5 m | up to 2,200 lb / 998 kg |
| G-11 | Heavy | 100 ft / 30.5 m | up to 5,000 lb / 2,268 kg |
Procurement
Looking for a specific NSN or part number?
Submit the known identification data. WHA will review the relationship between product, variant, NSN, reference number and parent system before responding.
- NSN and P/N fields are optional
- Variant-level identification is preserved
- RFQ and tender documents may be attached
